3.7V Lipo 853043 1200mAh Rechargeable Lithium ion Polymer Battery With Protection Board
Lipo battery Specification:
| Product Name | Lipo battery 853043 1200mAh |
| Battery Type | Lithium polymer battery |
| PCM | yes | |
| Accembly Composed Type | 1S1p/ 1 cell | |
| Nominal Capacity | 1200 mAh | @0.2C discharge |
| Nominal Voltage | 3.7 V | |
| Charge Voltage | 4.2±0.12 V | |
| Cut-off Voltage | 3.0 V | |
| Standard charge Current | 240mA | @0.2C charge |
| Max. charge current | 1200 mA | @1C charge |
| Standard Discharge Current | 240 mA | @0.2C discharge |
| Max. Discharge Current | 1200 mA | @1C discharge |
| Resistance | ＜20 mΩ | |
| Cycle Life: | Over 500 times | |
| Weight (Approx.) | 22 g | |
| Dimensions(T.W.L.) | 8.5*30*43 (mm) | |
| Charge Temperature | 0 ~ 45℃ | |
| Discharge Temperature | -20 ~ 60℃ | |
| Storage Temperature | -10~40℃ | Less than one month |
| 0~30℃ | More than one month |
| Protection Function(PCM) | Over charge, Over discharge,
Over load, Short Circuit |
| Warranty | 1 year from shipment date |
Advantage:
a.Fast delivery ,Top quality ;
b.First class after - sales service;
c.High energy density,Long cycle life;
d. Capacity, resistance, Voltage, platform time consistency is good;
e. With short-circuit production function, safe and reliable.
OEM/ODM service:
We have engineers, professional design team for your OEM service requirements. And we can design the products according to the specific requirements of the customers'.
Why choose us?
FAQ:
Q: Are you manufacturer?
A: Yes, we are. You are warmly welcome to visit our factory if you have interest!
Q: Is OEM/ODM available?
A: Yes, it is. Please feel free to tell us your application and your basic battery requirements. Our R&D team will provide a full solution to your with these factors taken into consideration: working temperature, dimension, compound mode, power, capacity, peak current, PCM, fuse, motion control ICs, plug, etc.
Q: Can you provide samples?
A: Yes, we can. After discousion and designing with our sales and engineer, we encourage client to order samples to test our battery quality first.
Q: What safety protection function does the PCM have?
A: Short circuit protection, over-current protection,over-load protection, over-discharge protection, inversely-connection protection, temperature control, balance, fuse, thermistor, etc. Our engineer will choose particular function to use for your battery pack in accordance with your specific situation.
Q: Are there related certificates about battery?
A: If required, we could apply CE, ROHS, CB(IEC62133), UL, KC, PSE, BIS, UN38.3 etc.
|
|
